2-7. Parts Layout in Inverter Assembly
8, 10, 12, 14HP
Model: MMY-MUP0801*, MUP1001*, MUP1201*, MUP1401*
Inverter P.C. board
for Compressor (1)
(MCC-1729)
Communication terminal block
Power supply terminal block
Noise Filter P.C. board (1)
(MCC-1748)
Magnet
Thermistor
Contactor
Remove the Interface P.C. board sub-assembly.
The Interface P.C. board sub-assembly
Interface P.C. board
(MCC-1747)
Inverter P.C. board for fan
(MCC-1734)
50
- 25 -
