Toshiba MMY-MUP2001HT8P-A User Manual

2-8-4. Inverter P.C. board for fan (MCC-1734)
190mm
UART communication
CN802,CN803
Vcc input
CN100
Vcc output
CN101
Vdc input from COMP
CN01
Vdc input from COMP
CN02
For inverter address setting
SW800
Fan motor output
CN301
+%
%0
%0 %0 %0
%0
%0
%0
+%
%0
59
%
%0
(
- 31 -
