Appendix F
Appendix F Wiring Diagrams
F.1 RGB Monitor ID Wraparound connector
(1) RED
(2) GREEN
(3) BLUE
(4) NC
(5) GND
(6) GND
(7) GND
(8) GND
(9) 5V
(10) GND
(11) NC
(12) SDA
(13) HSYNC
(14) VSYNC
(15) SDL
RED (1)
GREEN (2)
BLUE (3)
NC (4)
GND (5)
GND (6)
GND (7)
GND (8)
5V (9)
GND (10)
NC (11)
SDA (12)
HSYNC (13)
VSYNC (14)
SCL (15)
Figure F-1 RGB Monitor ID Wraparound connector (15PIN to 15PIN)
F.2 LAN loopback Connector
(1)
BIBAP
‘
(TX
+
)
(
2
)
BIDAN (TX-)
(
3
)
BIDBP
(
RX+
)
(4) BIDBN (RX-)
Figure F-2 LAN loopback connector
QOSMIO G20 Maintenance Manual (960-511) [CONFIDENTIAL] F-1
