Toshiba TC Series User Manual

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual
73
6.2 TC200S series
This address can be specified as system data area.
Device Bit Address Word Address 32 bits Notes
Input Relay 1 X000 - XF7F X00W - XF7W
*1
*1 Device format is as follows:
Please refer to the manual of external device for more detail.
Input Relay 2 I000 - IF7F I00W - IF7W
*1
Output Relay 1 Y000 - YF7F Y00W - YF7W
*1
Output Relay 2 O000 - OF7F O00W - OF7W
*1
Internal Relay R000 - R77F R00W - R77W
*1
Extended Internal Relay 1 G000 - GF7F G00W - GF7W
*1
Extended Internal Relay 2 H000 - HF7F H00W - HF7W
*1
Extended Internal Relay 3 J000 - JF7F J00W - JF7W
*1
Extended Internal Relay 4 K000 - KF7F K00W - KF7W
*1
Special AUX Relay A000 - A16F A00W - A16W
*1
Latch Relay L000 - L07F L00W - L07W
*1
Shift Register S000 - S07F S00W - S07W
*1
Edge Relay E000 - E77F E00W - E77W
*1
Timer (contact) T000 - T77F T00W - T77W
*1 *2
*2 The addresses of the timer (contact) range from T00W to T77W, however the internal memory area is not
consecutive. This range is divided into two areas, e.g., T00W to T37W and T40W to T77W.
Counter (contact) C000 - C77F C00W - C77W
*1 *3
*3 The addresses of the counter (contact) range from C00W to C77W, however the internal memory area is
not consecutive. This range is divided into two areas, e.g., C00W to C37W and C40W to C77W.
Timer/Counter (current value) ------ P000 - P77F
*1
Timer/Counter (setup value) ------ V000 - V77F
*1
Generic Register 1 ------ D000 - DF7F
*1
Generic Register 2 ------ B000 - BF7F
*1
Generic Register 3 ------ U000 - UF7F
*1
Generic Register 4 ------ M000 - MF7F
*1
Generic Register 5 ------ Q000 - QF7F
*1
• Please refer to the GP-Pro EX Reference Manual for system data area.
Cf. GP-Pro EX Reference Manual "LS Area (Direct Access Method Area)"
• Please refer to the precautions on manual notation for icons in the table.
)"Manual Symbols and Terminology"
E.g.
X F
7 W
Register Word Specified
Position (0 to 7)
Rack No. (0 to F)
D F
7 F
Port No. (0 to F)
Position (0 to 7)
Rack No. (0 to F)
