Toshiba TC Series User Manual

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual
76
 TC6-00
This address can be specified as system data area.
Device Bit Address Word Address 32 bits Notes
External Input
Relay
Photo coupler X000 - X00F X00W - X00W
*1
*1 Device format is as follows:
Please refer to the manual of external device for more detail.
Push-button
switch
X100 - X11F X10W - X11W
*1
External Output
Relay
Relay Y020 - Y02F Y02W - Y02W
*1
Panel LED Y160 - Y16F Y16W - Y16W
*1
External Input Output Relay
X030 - X13F X03W - X13W
*1
X148 - XF7F X14W - XF7W
*1
Y030 - Y13F Y03W - Y13W
*1
Y148 - YF7F Y14W - YF7W
*1
I000 - IF7F I00W - IF7W
*1
O000 - OF7F O00W - OF7W
*1
Internal Relay R000 - R77F R00W - R77W
*1
Extended Internal Relay 1 G000 - GF7F G00W - GF7W
*1
Extended Internal Relay 2 H000 - HF7F H00W - HF7W
*1
Extended Internal Relay 3 J000 - JF7F J00W - JF7W
*1
Extended Internal Relay 4 K000 - KF7F K00W - KF7W
*1
Edge Relay E000 - E77F E00W - E77W
*1
Latch Relay L000 - L07F L00W - L07W
*1
Shift Register S000 - S07F S00W - S07W
*1
Timer Relay T000 - T77F T00W - T77W
*1
Counter Relay C000 - C77F C00W - C77W
*1
T/C Register 1 ------ P000 - P77F
*1
T/C Register 2 ------ V000 - V77F
*1
Generic Register 1 ------ D000- DF7F
*1
Generic Register 2 ------ B000- BF7F
*1
Generic Register 3 ------ U000- UF7F
*1
Generic Register 4 ------ M000- MF7F
*1
Generic Register 5 ------ Q000- QF7F
*1
E.g.
X 0
0 W
Register Word Specified
Position (0 to 7)
Rack No. (0 to F)
D F
7 F
Port No. (0 to F)
Position (0 to 7)
Rack No. (0 to F)

Toshiba TC Series Specifications

General

Brand	Toshiba
Model	TC Series
Category	Control Unit
Language	English
