Toshiba TOSVERT VF-AS1 Function Manual

E6581288①
− 15 −
4.4.3. Instruction Codes
Code No. Item Description
1003H Command mode selection read
2003H Command mode selection write
0: Terminal input enabled
1: Operation panel input enabled
(including LED/LCD option input)
2: 2-wire RS485 communication input
3: 4-wire RS485 communication input
4: Communication option input
1004H
Frequency setting mode
selection read
2004H
Frequency setting mode
selection write
1: VI/II (voltage/current input)
2: RR/S4 (potentiometer/voltage input)
3: RX (voltage input)
4: Operation panel input enabled
(including LED/LCD option unit)
5: 2-wire RS485 communication input
6: 4-wire RS485 communication input
7: Communication input
8: Optional AI1 (differential current input)
9: Optional AI2 (voltage/current input)
10: UP/DOWN frequency
11: Optional RP pulse input
12: Optional high-speed pulse input
13: Optional binary/BCD input
0072H Special monitor
0000H to FFFFH : Monitor value selected after choosing
instruction code 00F3H.
0073H Read Special monitor code read Read the content that was monitored by special monitor.
00F3H Write Special monitor selection Select the monitor code of special monitor.
0074H Trip history No.1, No.2 read
0075H Trip history No.3, No.4 read
Read the No.1 (latest) to No.4 (oldest) trip records. *1
006DH Frequency command value (RAM) read Read the frequency command value (RAM).
006EH Torque command value (RAM) read Read the torque command value (RAM).
00EDH
Option frequency command value
(EEPROM&RAM) write *2
Write the option frequency command value (EEPROM
&RAM).
00EEH
Option torque command value
(EEPROM&RAM) write *2
Write the option torque command value (EEPROM&RAM).
00F4H Trip history clear 9696H : Clear all trip history.
00FCH Parameter all clear
9696H : Clear all parameters. (Parameters other than
proofreading values are made into factory default
settings.)
00FDH Inverter reset 9696H : Reset the inverter.
1000H to
1999H
(1000H to
1F99H)
Read parameters (RAM)
To read parameters F000 to F984, add the triple figures
that follow Fxxx to 1000H. (Ex: F984 -> 984
+ 1000 = 1984)
No error occurs when you select 1A00 to 1F99. Because
these parameters are for maintenance.
2000H to
2999H
Write parameters (EEPROM&RAM) *2
To write parameters F000 to F984, add the triple figures
that follow Fxxx to 2000H.
*1 : The details of an error code are indicated to the following page.
*2 : The Life of EEPROM is approximately ten thousand times.
