E6581288①
− 18 −
4.4.6. Description of monitor code
Divide the monitor code (RWw n) into half and select the first monitor data (RWr n) from
the lower 8 bits and the second monitor data (RWr n) from the higher 8 bits.
(Example) When output voltage is selected for the first monitor and output torque is
selected for the second monitor. -> The monitor code is 0703H.
RWw n Monitor code
the higher 8 bits the lower 8 bits
Second monitor description First monitor description
Monitor code (When an invalid monitor code is set up, monitor value fixes to 0.)
Code Number
Second Monitor Description
(the higher 8 bits)
First Monitor Description
(the lower 8 bits)
Unit
00H Output frequency None monitor (Monitor value is 0) 0.01Hz
01H Output frequency Output frequency 0.01Hz
02H *1 Output current Output current 0.01A
03H Output voltage Output voltage 0.1V
04H None monitor (Monitor value is 0) None monitor (Monitor value is 0)
−
05H Frequency command value Frequency command value 0.01Hz
06H None monitor (Monitor value is 0) None monitor (Monitor value is 0)
−
07H Output torque Output torque 0.1%
08H DC voltage DC voltage 0.1V
09H PBR load factor PBR load factor 0.1%
0AH Motor overload factor (OL2 data) Motor overload factor (OL2 data) 0.1%
0BH, 0CH None monitor (Monitor value is 0) None monitor (Monitor value is 0)
−
0DH Input power Input power 0.01kW
0EH Output power Output power 0.01kW
0FH Input terminal information Input terminal information
−
10H Output terminal information Output terminal information
−
11H Output current (% monitor) Output current (% monitor) 0.1%
12H Exciting current Exciting current 0.01A
13H None monitor (Monitor value is 0) None monitor (Monitor value is 0)
−
14H Cumulative operation time Cumulative operation time 1h
15H, 16H None monitor (Monitor value is 0) None monitor (Monitor value is 0)
−
17H Accumulation power supply ON time Accumulation power supply ON time 1h
18H Motor overload factor Motor overload factor 0.1%
19H Integral input power Integral input power 1kWh
1AH Integral output power Integral output power 1kWh
1BH RR/S4 input RR/S4 input
−
1CH VI/II input VI/II input
−
1DH RX input RX input
−
1EH, 1FH None monitor (Monitor value is 0) None monitor (Monitor value is 0)
−
20H Torque command Torque command 0.1%
21H Torque current Torque current 0.1%
22H, 23H None monitor (Monitor value is 0) None monitor (Monitor value is 0)
−
24H PID feedback value PID feedback value 0.01Hz
25H to 2FH None monitor (Monitor value is 0) None monitor (Monitor value is 0)
−
*1: The monitor code "02H" will be overflow when its value more than 327.67A. If that monitor overflowed, use
the monitor code "11H".
