4.4.7. Description of input terminal information
Data composition of input terminal information (Code No. = 0FH).
Bit Terminal name Function (parameter name) 0 1
0 F Input terminal function selection 1(f111)
1 R Input terminal function selection 2(f112)
2 ST Input terminal function selection 3(f113)
3 RES Input terminal function selection 4(f114)
4 S1 Input terminal function selection 5(f115)
5 S2 Input terminal function selection 6(f116)
6 S3 Input terminal function selection 7(f117)
7 S4 Input terminal function selection 8(f118)
8 L1 Input terminal function selection 9(f119)
9 L2 Input terminal function selection 10(f120)
10 L3 Input terminal function selection 11(f121)
11 L4 Input terminal function selection 12(f122)
12 L5 Input terminal function selection 13(f123)
13 L6 Input terminal function selection 14(f124)
14 L7 Input terminal function selection 15(f125)
15 L8 Input terminal function selection 16(f126)
OFF ON
4.4.8. Description of output terminal information
Data composition of input terminal information (Code No. = 10H).
Bit Terminal name Function (parameter name) 0 1
0 OUT1 Output terminal function selection 1(f130)
1 OUT2 Output terminal function selection 2(f131)
2 FL Output terminal function selection 3(f132)
3 OUT3 Output terminal function selection 4(f133)
4 OUT4 Output terminal function selection 5(f134)
5 R1 Output terminal function selection 6(f135)
6 OUT5 Output terminal function selection 7(f136)
7 OUT6 Output terminal function selection 8(f137)
8 R2 Output terminal function selection 9(f138)
9 R3 Output terminal function selection 10(f168)
10 R4 Output terminal function selection 11(f169)
OFF ON
11 to 15
−
−−−
