Toshiba TOSVERT VF-nC1 User Manual

E6581090
I-7
9
Tab le 4. AIC and fuse
Voltage class
Capacity of
applicable motor
(kW)
Inverter model
AIC
(Interrupting
capacity）
Fuse class and
currents（A）
0.1 VFNC1S-1001P AIC 1000A CC/J 6 max
0.2 VFNC1S-1002P AIC 1000A CC/J 8 max
0.4 VFNC1S-1004P AIC 1000A CC/J 12 max
Single-phase
100V class
0.75 VFNC1S-1007P AIC 1000A CC/J 22 max
0.2 VFNC1S-2002P(L) AIC 1000A CC/J 4 max
0.4 VFNC1S-2004P(L) AIC 1000A CC/J 8 max
0.75 VFNC1S-2007P(L) AIC 1000A CC/J 12 max
1.5 VFNC1S-2015P(L) AIC 5000A CC/J 22 max
Single-phase
200V class
2.2 VFNC1S-2022P(L) AIC 5000A CC/J 30 max
0.1 VFNC1-2001P AIC 1000A CC/J 3 max
0.2 VFNC1-2002P AIC 1000A CC/J 3 max
0.4 VFNC1-2004P AIC 1000A CC/J 5 max
0.75 VFNC1-2007P AIC 1000A CC/J 8 max
1.5 VFNC1-2015P AIC 5000A CC/J 15 max
Three-phase
200V class
2.2 VFNC1-2022P AIC 5000A CC/J 20 max
9.2.4 Motor thermal protection
Selects the electronic thermal protection characteristics that fit with the ratings and characteristics
of the motor. In case of multi motor operation with one inverter, thermal relay should be connected
to each motor.
