12. Specifications
12.1 Models and their standard specifications
■Standard specifications
Item Specification
Input voltage 3-phase 200V
Applicable motor (kW) 0.1 0.2 0.4 0.75 1.5 2.2
Type VFNC1
Form 2001P 2002P 2004P 2007P 2015P 2022P
Capacity (kVA) Note 1) 0.3 0.6 1.0 1.6 2.9 3.9
Rated output current (A)
Note 2)
0.7 1.4 2.4 4.0 7.5 10.0
Rated output voltage
Note 3)
3-phase 200V to 240V
Rating
Overload current rating 60 seconds at 150%, (50%-reduction value)
Voltage-frequency 3-phase 200V to 240V - 50/60Hz
Allowable fluctuation
25/Voltage +10%, -15% Note 4), frequency ±5%
Power
supply
Ampere Interrupt
Capacity (A) AIC
1000 1000 1000 1000 5000 5000
Protective method IP20 Enclosed type (JEM 1030)
Cooling method Self-cooling Forced air-cooled
Color Munsel 5Y8/0.5
Charge lamp LED indicating the charge status of the capacitor in the main circuit
Built-in filter -
Item Specification
Input voltage 1-phase 200V
Applicable motor (kW) 0.1 0.2 0.4 0.75 1.5 2.2
Type VFNC1S
Form - 2002P 2004P 2007P 2015P 2022P
Capacity (kVA) Note 1) - 0.6 1.0 1.6 2.9 3.9
Rated output current (A)
Note 2)
-1.42.44.07.510.0
Rated output voltage
Note 3)
3-phase 200V to 240V
Rating
Overload current rating 60 seconds at 150%, (50%-reduction value)
Voltage-frequency 1-phase 200V to 240V - 50/60Hz
Allowable fluctuation
Voltage +10%, -15% Note 4), frequency ±5%
Power
supply
Ampere Interrupt
Capacity (A) AIC
-10001000 1000 5000 5000
Protective method IP20 Enclosed type (JEM 1030)
Cooling method - Self-cooling Forced air-cooled
Color Munsel 5Y8/0.5
Charge lamp LED indicating the charge status of the capacitor in the main circuit
Built-in filter -
