7.2.4 Configuration of RAS information
In the RAS information area, the information for all nodes is shared. The state
information of each node is updated periodically, which consists of 64 words per
node.
The configuration information depends on the node type. The information of
each node is expanded at the position of the station number x 128 bytes from
the beginning of the RAS information area by 64 words.
Figure 7-8 shows the configuration of the information provided by TN8 and
TNB.
Word
No.
F 8 7 0
Update
cycle
Remarks
0 Module type (Note 1) Reserved 1s
1 Healthy counter 1s
2 Reserved
－
3 Reserved
－
・
・
・
・
・
・
63 Reserved
－
(Note 1)
：
Module Type 23H
：
TN8
、
4
：
TNB
Figure 7-8 Configuration of RAS information
