Appendix A Specifications
6F8C1637
72
A.1 General Specifications
Table A-1 General specifications
Item
Specification
TNB21 TNB22
Operating temperature
(Ambient temperature)
0 to 55

C
Operating humidity 10 to 95%RH (without condensation)
Storage temperature -40 to 70

C
Power source voltage 5.0Vdc ± 5%
Current consumption
(at rated voltage input)
2.4A or less 2.8A or less
Power consumption
(at rated voltage input)
10W or less 14W or less
Dust density 0.3mg/m
3
or less (no conductive dust)
Vibration resistance Compliant with IEC 60068-2-6, test Fc standard
10 cycles each 3-axis directions, orthogonal
Shock resistance Compliant with IEC 60068-2-27, test Ea standard
147m/S
2
(3 times each 3-axis directions, orthogonal)
Grounding Class D grounding (grounding resistance of 100Ω or less)
Cooling Forced air cooling by main unit fan
Module Dimensions 71mm(W)x150mm(D)x135mm(H)
Weight Approx. 600g
Online Maintenance Not Available
Table A-2 TNB21/TNB22 module specifications
Item Specifications
Bus interface PCI Express Gen2 compliant
PCI operation mode EndPoint mode
PCI transmission mode PIO access, DMA access
PCI data transmission speed 5Gbps (1 lane)
Dedicated slot 2 slots
No. of installation
Single base: max. 3
Multiple base: max. 1
Memory backup Not available
