Toto Washlet Series User Manual

50 51
Specifi cations
Item TCF895CG, TCF894CG TCF897CG, TCF896CG
Rated power supply AC 220-240 V, 50 Hz
Rated power consumption 843-853 W 849-860 W
Maximum power consumption
1454-1468 W
<When the water supply
temperature is 0 °C>
1461-1476 W
<When the water supply
temperature is 0 °C>
Type of water heater Instantaneous type
Power cord length 0.9 m
Water protection level IPX4
Cleansing
Spray
volume
Rear cleansing Approx. 0.27-0.43 L/min. <at 0.20 MPa water pressure>
Rear soft cleansing Approx. 0.27-0.43 L/min. <at 0.20 MPa water pressure>
Front cleansing Approx. 0.29-0.43 L/min. <at 0.20 MPa water pressure>
Water temperature Adjustable temperature range: OFF, about 35-40 °C
Heater capacity 1200-1428 W
Safety device Temperature fuse
Backfl ow prevention device Air gap (according to EN1717), Vacuum breaker
Heated seat
Surface temperature
Adjustable temperature range: OFF, about 28-36 °C
(Auto energy saver: about 26 °C, Auto energy saver+: OFF)
Heater capacity 55-65 W 61-72 W
Safety device Temperature fuse
Deodorizer
Method O
2
deodorization
Airfl ow volume Normal mode: Approx. 0.09 m
3
/min, Power mode: Approx. 0.16 m
3
/min
Power consumption Normal mode: Approx. 1.7 W, Power mode: Approx. 5.3 W
Water supply pressure
Minimum required water pressure: 0.1 MPa <dynamic>,
Maximum water pressure: 1.0 MPa <static>
Water supply temperature
0-35 °C
Working ambient temperature 0-40 °C
Dimensions W 386 mm x D 579 mm x H 146 mm
Weight About 7 kg
Safety Guidelines
A warm-water cleaning toilet seat is
an electric appliance.
For safe use of the warm-water
cleaning toilet seat
Continued use after malfunction occurs or use when its life-time is
expired may deteriorate the electric components, producing smoke
or resulting in a fire.
If any abnormality of the product is
observed, stop using it and consult
the installer, seller or the contact
listed on the back cover of this
manual.
(A damaged product may cause a fire, electric shock, or may
flood the floors with water.)
󱓻Turn off the power immediately and close the shutoff valve.
Reference

Toto Washlet Series Specifications

General

Category	Toilets
Brand	Toto
Self-Cleaning Nozzle	Yes
Series	Washlet
Water Pressure	Adjustable
Water Temperature Control	Yes
Seat Temperature Control	Yes
Air Dryer Temperature Control	Yes
Nozzle Position Adjustment	Yes
Nozzle Cleaning	Yes
Energy Saving Mode	Yes
Automatic Lid	Available on select models
Water Pressure Adjustment	Yes
Dimensions	Varies by model
Weight	Varies by model
Color Options	Sedona Beige
Power Supply	Electric
Power Source	AC 120V
