DIFFERENTIAL CASE ASSY
DISASSEMBLY INSPECTION
-
REASSEMBLY
T
=
N-m
(kgf
-
cm) [ft-lbfl
Disassembly Procedure
1
Remove the differential case bearings.
[Point
I]
2
Remove the differential upper case.
[Point
21
3
Remove the side gear and pinion gear.
[Point
31
4
Remove the ring gear.
[Point
41
Reassembly Procedure
The reassembly procedure is the reverse of the disassembly procedure.
