REASSEMBLY (QFV)
1. Installing direction
As shown in the table below.
2. Chain adjusting nut tightening order
(I) Tighten nuts @ and 0. T = 49.0 - 78.0 N.m (500 - 800 kgf - cm) [36.2 - 57.9 fi-lbfl
(2) Tighten nut @.
Outer chain
Clamp $ ZZ
y7
T = 98.0 - 147.0 Nm (1 000 - 1500 kgf - cm)
[72.35 - 108.5 ft-lbfl
Upper middle
&
0
T = 98.0 - 147.0 N.m (1000 - 1500 kgf-cm)
[72.35 - 108.5 ft-lbfl
Chain connection
Middle chain
clamp 5s
Split pin
lnner mast
Installation side of split pin is at center
side of the truck.
Inner chain
@ yw5 $:&r
Installation side of split pin is outward of
the truck center.
