Rear Lift Cylinder
(QFV)
SPECIFICATIONS
Lift Cylinder
O/)
3
ton series
Single
-
acting
55.0 (2.1
7)
45.0 (1.77)
U
packing
U
packing
Vehicle model
2
ton series
Itern
Cylinder type
Cylinder bore mrn (in)
Piston rod outside diameter rnm (in)
Piston seal type
Rod seal type
Single
-
acting
50.0 (1.97)
42.0 (1.65)
U
packing
U
packing
Others
Built
-
in safety down valve (RH,
LH)
