TP-Link ARCHER C3150 User Manual

101
Chapter 13
Manage the Router
2. Go to Advanced > System Tools > Traffic Statistics.
3. Enable traffic statistics, and then you can monitor the traffic statistics in Traffic
Statistics List section.
Click Refresh to update the statistic information on the page.
Click Reset All to reset all statistic values in the list to zero.
Click Delete All to delete all statistic information in the list.
Click
to reset the statistic information of the specific device.
Click
to delete the specific device item in the list.
13. 11. Control LEDs
The router LEDs indicate router activities and behavior. You can turn on or turn off the
router from the management web-page.
1. Visit http://tplinkwifi.net, and log in with the username and password you set for the
router.
2. Go to Advanced > System Tools > System Parameters.
3. In the Led section, enable Night Mode.

TP-Link ARCHER C3150 Specifications

General

Modulation	1024-QAM
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2167 Mbit/s
WLAN data transfer rate (first band)	1000 Mbit/s
Certification	CE, FCC, RoHS
Built-in processor	Yes
Processor frequency	1400 MHz
Memory card slot(s)	-
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Product type	Portable router
Product color	Black
SIM card slot	No
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Security algorithms	64-bit WEP, 128-bit WEP, IPSEC, WPA, WPA-PSK, WPA2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Power source type	AC
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	197.8 mm
Width	263.8 mm
Height	37.3 mm
