TP-Link ARCHER C3150 User Manual

62
Chapter 10
NAT Forwarding
10. 1. Share Local Resources on the Internet by Virtual
Servers
When you build up a server in the local network and want to share it on the Internet,
Virtual Servers can realize the service and provide it to the Internet users. At the same
time Virtual Servers can keep the local network safe as other services are still invisible
from the Internet.
Virtual Servers can be used for setting up public services in your local network, such
as HTTP, FTP, DNS, POP3/SMTP and Telnet. Different service uses different service port.
Port 80 is used in HTTP service, port 21 in FTP service, port 25 in SMTP service and port
110 in POP3 service. Please verify the service port number before the configuration.
Share my personal website I’ve built in local network with my
friends through the Internet.
For example, the personal website has been built on my home
PC (192.168.0.100). I hope that my friends on the Internet can
visit my website in some way. The PC is connected to the router
with the WAN IP address 218.18.232.154.
Personal Website
Home
Router
WAN: 218.18.232.154LAN
1. Assign a static IP address to your PC, for example
192.168.0.100.
2. Visit http://tplinkwifi.net, and log in with the username and
password you set for the router.
3. Go to Advanced > NAT Forwarding > Virtual Servers.
4. Click Add. Click View Existing Applications and select
HTTP. The External Port, Internal Port and Protocol will be
automatically filled with contents. Enter the PC’s IP address
192.168.0.100 into the Internal IP field.
5. Click OK.
I want to:
How can I
do that?
INTERNET

TP-Link ARCHER C3150 Specifications

General

Modulation	1024-QAM
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2167 Mbit/s
WLAN data transfer rate (first band)	1000 Mbit/s
Certification	CE, FCC, RoHS
Built-in processor	Yes
Processor frequency	1400 MHz
Memory card slot(s)	-
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Product type	Portable router
Product color	Black
SIM card slot	No
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Security algorithms	64-bit WEP, 128-bit WEP, IPSEC, WPA, WPA-PSK, WPA2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Power source type	AC
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	197.8 mm
Width	263.8 mm
Height	37.3 mm
