TP-Link RE580D User Manual

View the Information of
the Extender
This chapter covers the following topics:
 View the Extender’s Current Status

View the Information about the Host Network, the
Extender and the Clients
View the Extender’s Current
Status
1) Launch a web browser and type in http://tplinkrepeater.net, then go to
Settings > Status webpage.
2) You can view the network connection in the Status webpage.
● The normal status.
● The extender is failed to connect to the wireless network of your router.
● The extender is connected to the wireless network of your router, but no
transmitting data. Please check your host network.
● The extender is connected to the router unnormally. Maybe the gateway
is set incorrectly in the Static IP. You can select “Obtain an IP address
automatically” on the “LAN Settings” page.
3
View the Information of the Extender 12

TP-Link RE580D Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Windows operating systems supported	Yes
Certification	CE, FCC
Antennas quantity	3
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Wi-Fi data rate (max)	1900 Mbit/s
Ethernet LAN (RJ-45) ports	5
Output current	2.5 A
Output voltage	12 V
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 30 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	240 mm
Package width	340 mm
Package height	76 mm
Sustainability certificates	RoHS
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	162 mm
Width	242 mm
Height	44 mm
