TP-Link RE580D User Manual

6) Relocate.
Plug in the extender halfway between your wireless router (Host Network)
and the Wi-Fi dead zone.
Wait for the extender to reconnect and the LED turns solid blue. If
not, relocate it closer to the router to achieve a good (or better) signal
quality.
Enjoy!
The extender shares the same wireless network name (SSID) and wireless
password as your host network. If you want to change the wireless network
name (SSID), please refer to Extended Settings
.
Extender Settings
On the Extended Network page, you can enable or disable the wireless network
of the extender, change and hide the wireless network name (SSID) of the
extender.
1) Launch a web browser and type in http://tplinkrepeater.net, then go to
Settings->Wireless-> Extended Network webpage.
2) Configure the settings as shown in the figure below.
 Extended 2.4GHz/5GHz: Enable or disable the 2.4GHz/5GHz
wireless function of the extender.
 Extended 2.4GHz/5GHz SSID: Either copy the host SSID or create a
new name using up to 32 characters. This field is case-sensitive.
 Hide SSID broadcast: Select this checkbox if you want to hide the
extender’s SSID (of the 2.4GHz or 5GHz wireless network) from the
Wi-Fi network list. If you want to connect to the hiden SSID, please
enter the SSID and the password manaully.
3) Click Save to save the settings.
Manage the Extended Network and Security Settings 16

TP-Link RE580D Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Windows operating systems supported	Yes
Certification	CE, FCC
Antennas quantity	3
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Wi-Fi data rate (max)	1900 Mbit/s
Ethernet LAN (RJ-45) ports	5
Output current	2.5 A
Output voltage	12 V
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 30 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	240 mm
Package width	340 mm
Package height	76 mm
Sustainability certificates	RoHS
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	162 mm
Width	242 mm
Height	44 mm
