TP-Link TL-WA801N User Manual

17
Chapter 3 Customize Your Network
3. Enter the SSID and the password of a host network which the extender will be
connected to or click Scan and select a Wi-Fi network.
4. Click Save and the modified configuration will be synchronized to the extended
network settings.
3. 3. 4. Customize the Extended Network (Range Extender mode)
1. Visit http://tplinkap.net, and log in with the password you set for the access point.
2. Go to Wireless > Extended Network.
3. Modify the SSID and the password of the extended network.
Tip:
SSID Broadcast is enabled by default. If you want to hide the SSID of the extended network, deselect Enable SSID
Broadcast, and then the corresponding SSID will not be displayed when wireless devices scan for local wireless networks.
3. 4. Use WPS for Wireless Connection (Access Point
mode)
Wi-Fi Protected Setup (WPS) provides an easier approach to set up a security-protected
Wi-Fi connection.
Note:
• The WPS function cannot be configured if the wireless function of the access point is disabled. Please
make sure the wireless function is enabled before configuration.
• When working in Range Extender, Client or Multi-SSID mode, the WPS funcion of the access point is not
available.
• The WPS function is enabled by default. You can go to Wireless > WPS to disable the function as needed.

TP-Link TL-WA801N Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4-2.4835 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Receiver sensitivity	11g 6Mbps: -90dBm 11g 54Mbps: -77dBm 11n HT20 MC7: -73dBm 11n HT40 MC7: -70dBm
Ethernet LAN data rates	10, 100 Mbit/s
Transmitting power (CE)	15 dBm
Transmitting power (FCC)	20 dBm
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power over Ethernet (PoE) type supported	Passive PoE
Placement	Table
Certification	CE, FCC, RoHS
Product color	White
Antenna type	External
Antennas quantity	2
Antenna direction type	Omni-directional
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package type	Box
Package depth	223 mm
Package width	310 mm
Package height	70 mm
Package weight	560 g
Cables included	LAN (RJ-45)
Number of products included	1 pc(s)
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	129.7 mm
Width	181.6 mm
Height	34.7 mm
