TP-Link TL-WA801N User Manual

26
Chapter 4 Manage Your Access Point
4. 1. Set Up System Time
System time is the time displayed while the access point is running. The system time
you configure here will be used for other time-based functions like Reboot Schedule.
You can choose the way to obtain the system time as needed.
Note:
When working in Client/Multi-SSID mode, setting up system time is not available.
1. Visit http://tplinkap.net, and log in with the password you set for the access point.
2. Go to System Tools > Time Settings.
3. Configure the system time using the following methods:
• Manually - Select your time zone and enter your local time.
• Get from PC - Click this button if you want to use the current managing PC’s
time.
• Get GMT - Click this button if you want to get time from the internet. Make sure
your router can access the internet before you select this way to get system
time.
4. Click Save to make your settings effective.
5. After setting the system time, you can set Daylight Saving time according to your
needs. Select Enable Daylight Saving, set the start and end time and then click Save.

TP-Link TL-WA801N Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4-2.4835 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Receiver sensitivity	11g 6Mbps: -90dBm 11g 54Mbps: -77dBm 11n HT20 MC7: -73dBm 11n HT40 MC7: -70dBm
Ethernet LAN data rates	10, 100 Mbit/s
Transmitting power (CE)	15 dBm
Transmitting power (FCC)	20 dBm
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power over Ethernet (PoE) type supported	Passive PoE
Placement	Table
Certification	CE, FCC, RoHS
Product color	White
Antenna type	External
Antennas quantity	2
Antenna direction type	Omni-directional
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package type	Box
Package depth	223 mm
Package width	310 mm
Package height	70 mm
Package weight	560 g
Cables included	LAN (RJ-45)
Number of products included	1 pc(s)
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	129.7 mm
Width	181.6 mm
Height	34.7 mm
