TP-Link TL-WPA8631P User Manual

8
Chapter 2
Initial Use
2. 1. To Set Up a New Secure Wireless Network
I want to:
Use the Powerline Wi-Fi Kit to set up a new secure wireless network in my house.
For example, I have a wireless router in my house, but the wireless signal cannot reach
every corner. So I bought a Powerline Wi-Fi Kit to extend the wireless network. The
Powerline Wi-Fi Kit includes a powerline adapter and a powerline extender.
How can I do that?
Method 1: Plug and Play
1. Connect the powerline adapter to an available LAN port of the router.
2. Plug the powerline adapter into a wall socket.
3. Plug the powerline extender into a wall socket near the adapter. Wait until the
extender’s Powerline LED
turns solid on.
Router
WAN LAN
Extender
TL-WPA8631P
Adapter TL-PA8010P
(For demonstration only)
Powerline
Ethernet Cable

TP-Link TL-WPA8631P Specifications

General

Universal Plug and Play (UPnP)	Yes
Networking standards	IEEE 1901, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DSL WAN	-
SIM card slot	No
Modulation	OFDM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Power supply	13 W
Power source type	AC
Power consumption (typical)	11 W
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN (RJ-45) ports	3
Antenna type	Internal
Certification	CE, RoHS
Product color	White
LED indicators	Activity, LAN, Power, WLAN
Security algorithms	128-bit AES
Power plug	Type G
Maximum operating distance	300 m
WLAN data transfer rates supported	300, 867 Mbit/s
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Package type	Box
Cables included	LAN (RJ-45)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	42 mm
Width	75 mm
Height	152 mm
