TP-Link TL-WPA8631P User Manual

32
Chapter 3
Conguring via Web Management Interface
3. Select the correct End date and time when daylight saving time ends at your local
time zone.
4. Click Save.
3. 11. 3. Upgrade the Firmware
TP-Link is dedicated to improving and richening the product features, giving you a better
network experience. We will release the latest firmware at TP-Link official website, you
can download the latest firmware file from our website: www.tp-link.com and upgrade
the firmware to the latest version.
1. Connect to the powerline extender wirelessly. Visit http://tplinkplc.net, and log in with
the username and password you set for the extender.
2. Go to System Tools > Firmware Upgrade page and confirm the Hardware Version.
3. Go to www.tp-link.com. Download the latest firmware file for the extender.
Note: The upgraded firmware version must correspond to the hardware.
4. Click Browse to locate the downloaded new firmware file, and click Upgrade.
5. Wait a few minutes for the upgrading and rebooting.
Note:
1. Before upgrading the firmware, it’s better to back up your current settings.
2. During the upgrading process, do not turn off or reset the extender.
3. 11. 4. Backup and Restore Configuration Settings
The configuration settings are stored as a configuration file in the extender. You can
back up the configuration file to your computer for future use and restore the extender
to a previous settings from the backup file when needed. Moreover, if needed, you can
erase the current settings and reset the extender to the default factory settings.
• To back up configuration settings:
1. Connect to the powerline extender wirelessly. Visit http://tplinkplc.net, and log in with
the password you set for the extender.
2. Go to System Tools > Backup & Restore page.

TP-Link TL-WPA8631P Specifications

General

Universal Plug and Play (UPnP)	Yes
Networking standards	IEEE 1901, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DSL WAN	-
SIM card slot	No
Modulation	OFDM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Power supply	13 W
Power source type	AC
Power consumption (typical)	11 W
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN (RJ-45) ports	3
Antenna type	Internal
Certification	CE, RoHS
Product color	White
LED indicators	Activity, LAN, Power, WLAN
Security algorithms	128-bit AES
Power plug	Type G
Maximum operating distance	300 m
WLAN data transfer rates supported	300, 867 Mbit/s
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Package type	Box
Cables included	LAN (RJ-45)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	42 mm
Width	75 mm
Height	152 mm
