TP-Link TL-WPA8631P User Manual

16
Chapter 3
Conguring via Web Management Interface
3. Click the add icon and enter the Powerline Key of the device you want to add. The
Powerline Key contains 16 capital letters, formed like XXXX-XXXX-XXXX-XXXX. It is
printed on the back of the powerline device.
4. Click Add to add the device.
3. 2. 2. Change Powerline Network Name
You can change the extender’s powerline network name to add it to or remove it from a
powerline network.
Follow the steps below to change the name.
1. Connect to the powerline extender wirelessly. Visit http://tplinkplc.net, and log in with
the password you set for the extender.
2. Go to Device Settings > Powerline.

TP-Link TL-WPA8631P Specifications

General

Universal Plug and Play (UPnP)	Yes
Networking standards	IEEE 1901, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DSL WAN	-
SIM card slot	No
Modulation	OFDM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Power supply	13 W
Power source type	AC
Power consumption (typical)	11 W
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN (RJ-45) ports	3
Antenna type	Internal
Certification	CE, RoHS
Product color	White
LED indicators	Activity, LAN, Power, WLAN
Security algorithms	128-bit AES
Power plug	Type G
Maximum operating distance	300 m
WLAN data transfer rates supported	300, 867 Mbit/s
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Package type	Box
Cables included	LAN (RJ-45)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	42 mm
Width	75 mm
Height	152 mm
