TP-Link WPA7517 User Manual

8
Chapter 2
Initial Use
5. Relocate the extender to the Wi-Fi “dead” zone. Use the SSID (network name) and
password on the label at the top of the extender.
Note: A blinking Powerline LED indicates poor signal strength. Move the extender to another location.
SSID:TP-Link_XXXX
SSID:TP-Link_XXXX_5G
Wireless Password:XXXXXXXX
SSID:TP-LINK_X
XXX
SSID:T
P
-LINK_XXXX_5G
Wireless Pass
w
o
r
d:XXXXXXXX
Now enjoy the internet!
2. 2. To Extend the Existing Wireless Network
Extend the existing wireless network by adding a new powerline extender to the existing
powerline network.
For example, I already set up a wireless network using powerline devices, but the
wireless network is still not big enough to reach the top floor. So I bought a new powerline
extender to extend the wireless network.
1. Plug the new powerline extender into a wall socket near one of the existing powerline
extender.
Done!
I want to:
How can I do that?

TP-Link WPA7517 Specifications

General

Plug Type	EU, UK
LED Indicator	Power, Powerline, Ethernet, Wi-Fi
Range	300 meters over electrical circuit
Security	128-bit AES Encryption
Frequency Band	2.4 GHz and 5 GHz
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Certification	CE, RoHS
Type	Powerline Extender
Wi-Fi Speed	433 Mbps on 5 GHz, 300 Mbps on 2.4 GHz
Wi-Fi Standard	802.11ac
Ethernet Ports	1
Standards and Protocols	HomePlug AV2, IEEE 1901
Button	Pair, Reset
Compatibility	Compatible with all HomePlug AV and AV2 standard powerline adapters
Transmission Speeds	Up to 1000 Mbps
Product Type	Powerline Extender
Antenna	2 x Internal Antennas
Power Supply	100-240V~ 50/60Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
