TP-Link WPA7517 User Manual

22
Chapter 3
Conguring via Web Management Interface
3. Toggle on Parental Controls.
4. Click Add.
5. Click Select from Device List and select the device to be controlled. Or select Add
Manually and enter the MAC address manually.
6. Choose Internet Access Time from 18:00 to 22:00, and then check all boxes from
Sunday to Saturday.
7. Give a description to the device to be controlled.
8. Click SAVE to save the settings.
Note: Please make sure that the system time is correct before using this function.
Now the controlled device can access only from 18:00 (6PM) to 22:00 (10PM) on
weekdays and not other times.
3. 9. Guest Network
Create a network for my guests, providing internet access for them while at the same
time limit the network authorities for guests to ensure network security and privacy.
1. Connect to the powerline extender wirelessly. Visit http://tplinkplc.net, and log in
with the password you set for the extender.
2. Go to Advanced > Guest Network.
3. Check the box of relative entry to limit network authorities.
4. Select 2.4GHz or 5GHz and configure the following settings.
Done!
I want to:
How can I do that?

TP-Link WPA7517 Specifications

General

Plug Type	EU, UK
LED Indicator	Power, Powerline, Ethernet, Wi-Fi
Range	300 meters over electrical circuit
Security	128-bit AES Encryption
Frequency Band	2.4 GHz and 5 GHz
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Certification	CE, RoHS
Type	Powerline Extender
Wi-Fi Speed	433 Mbps on 5 GHz, 300 Mbps on 2.4 GHz
Wi-Fi Standard	802.11ac
Ethernet Ports	1
Standards and Protocols	HomePlug AV2, IEEE 1901
Button	Pair, Reset
Compatibility	Compatible with all HomePlug AV and AV2 standard powerline adapters
Transmission Speeds	Up to 1000 Mbps
Product Type	Powerline Extender
Antenna	2 x Internal Antennas
Power Supply	100-240V~ 50/60Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
