TP-Link WPA7517 User Manual

4
Chapter 1
Get to Know Your Powerline Extender
Name Status Indication
Power
On/Off The powerline extender is on or off.
Blinking
Quickly: Pairing is in progress.
Slowly: Power-saving Mode is on.*(TL-PA7017 Only)
Powerline
On
The powerline extender is connected to the powerline
network and is in a suitable location.
Off
The powerline extender is not connected to any
powerline network.
Ethernet
On
At least one Ethernet port is connected to a powered-on
device.
Off No Ethernet port is connected to a powered-on device.
Wireless
On The wireless function is enabled.
Off The wireless function is disabled.
Blinking
Slowly: The powerline extender is cloning wireless
network settings from the main router.
Quickly: The powerline extender is syncing wireless
network settings.
1. 3. 2. Physical Interface
Plug
Pair/Reset Button
Ethernet Port
Wi-Fi Button
LED ON/Off Button

TP-Link WPA7517 Specifications

General

Plug Type	EU, UK
LED Indicator	Power, Powerline, Ethernet, Wi-Fi
Range	300 meters over electrical circuit
Security	128-bit AES Encryption
Frequency Band	2.4 GHz and 5 GHz
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Certification	CE, RoHS
Type	Powerline Extender
Wi-Fi Speed	433 Mbps on 5 GHz, 300 Mbps on 2.4 GHz
Wi-Fi Standard	802.11ac
Ethernet Ports	1
Standards and Protocols	HomePlug AV2, IEEE 1901
Button	Pair, Reset
Compatibility	Compatible with all HomePlug AV and AV2 standard powerline adapters
Transmission Speeds	Up to 1000 Mbps
Product Type	Powerline Extender
Antenna	2 x Internal Antennas
Power Supply	100-240V~ 50/60Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
