TP-Link WPA7517 User Manual

29
Chapter 3
Conguring via Web Management Interface
2. We strongly recommend you back up the current configuration settings before resetting the extender.
3. 11. 5. Change Login Password
Go to Settings > Change Login Password, and you can change the login password of
the extender.
Note:
1. The new password must be 6-32 characters long and not include any spacing.
3. 11. 6. System Log
When the extender does not work properly, you can save the system log and send it to
the technical support for troubleshooting.
Follow the steps below to save the system log:
1. Connect to the powerline extender wirelessly. Visit http://tplinkplc.net, and log in with
the password you set for the extender.
2. Go to Settings > System Log.
3. Choose the type and level of the system log according to your need.
4. Click SAVE LOG to save the system log to local.

TP-Link WPA7517 Specifications

General

Plug Type	EU, UK
LED Indicator	Power, Powerline, Ethernet, Wi-Fi
Range	300 meters over electrical circuit
Security	128-bit AES Encryption
Frequency Band	2.4 GHz and 5 GHz
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Certification	CE, RoHS
Type	Powerline Extender
Wi-Fi Speed	433 Mbps on 5 GHz, 300 Mbps on 2.4 GHz
Wi-Fi Standard	802.11ac
Ethernet Ports	1
Standards and Protocols	HomePlug AV2, IEEE 1901
Button	Pair, Reset
Compatibility	Compatible with all HomePlug AV and AV2 standard powerline adapters
Transmission Speeds	Up to 1000 Mbps
Product Type	Powerline Extender
Antenna	2 x Internal Antennas
Power Supply	100-240V~ 50/60Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
