Trane CCAF User Manual

46 CGWF-SVX01A-EN
Installation Electrical
Table 11 Electrical Data CCAF and CGWF High Condensing Temperature (90-130 F) Units
Unit Size Unit Wiring Data Compressor Motor Data
Rated
Voltage
Minimum
Circuit
Ampacity
Max Fuse
Size
Recommended
Duel Element
Fuse Size
Qty - Size RLA LRA
20 208/230 88 125 110 2 -10 39 251
380456060 20142
460385050 17117
575324540 1494
400/50 38 50 50 17 117
25 208/230 112 150 150 1 -15
1 - 10
58/39 376/251
380 59 80 80 31/20 215/142
460 50 70 70 26/17 178/117
575 40 60 60 21/14 143/94
400/50 48 70 70 25/17 178/117
30 208/230 131 175 175 2 - 15 58 376
380 70 100 90 31 215
460598080 26178
575476060 21143
400/50 56 80 80 25 178
40 208/230 166 200 200 4 - 10 39 251
380 85 100 100 20 142
460728090 17117
575607070 1494
400/50 72 80 90 17 117
50 208/230 209 250 250 2 - 15
2 - 10
58/39 376/251
380 110 125 150 31/20 215/142
460 93 110 110 26/17 178/117
575 75 90 90 21/14 143/94
400/50 90 110 110 25/17 178/117
60 208/230 247 300 300 4 - 15 58 376
380 132 150 150 31 215
460 111 125 125 26 178
575 89 100 110 21 143
400/50 106 125 125 25 178
Notes:
1. Minimum Circuit Ampacity is 125% of the largest compressor RLA plus 100% of the remaining compressor(s) RLA, per NEC 440-32 and NEC 440-33.
2. Maximum Fuse Size is 225% of the largest compressor RLA plus 100% of the remaining compressor(s) RLS, per NEC 440-30.
3. Recommended Dual-Element Fuse Size is 175% of the largest compressor RLA plus 100% of the remaining compressor(s) RLA, Per NEC 430-152.
4. Use copper conductors only.
5.Compressor motor Voltage utilization range is:
Rated Voltage--- Utilization Range
208/230 ---188-253
380 ---342-418
460 ---414-506
575 ---517-633
400/50 - 360-440
