Trane CCAF User Manual

66 CGWF-SVX01A-EN
Controls Interface
Evap Water Flow Switch Status Text
Cond Entering Water Te mp Te mp er at u r e X XX .X
Cond Leaving Water Temp Temperature XXX.X
Cond Water Flow Switch Status Text
Outdoor Air Temp Temperature XXX.X
Average Line Current (RLA) % X
Circuit ASHRAE Log
Circuit Mode Text
Evap Sat Rfgt Temperature XXX.X
Suction Pressure Pressure X
Evap Approach Temp Temperature XXX.X
Cond Sat Rfgt Temp Temperature XXX.X
Discharge Pressure Pressure X
Cond Approach Temp Temperature XXX.X
Compressor A Starts Integer XXXX
Compressor A Running Time Hours:Minute XX:XX
Compressor B Starts Integer XXXX
Compressor B Running Time Hours:Minute XX:XX
Historic Diagnostics
Table 20 Reports Screens
Description Units Resolution
