Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
Annual Maintenance
WARNING: Hazardous Voltage!
Disconnect all electric power, including remote
disconnects before servicing. Follow proper lockout
/ tagout procedures to ensure the power can not be
inadvertently energized. Failure to disconnect power
before servicing could result in death or serious injury.
• Shut down the chiller once each year to check the
following:
• Perform all weekly and monthly maintenance
procedures.
• Check the refrigerant charge and oil level. Refer to
“Maintenance Procedures “. Routine oil changing is not
necessary on a hermetic system.
• Have a qualified laboratory perform an oil analysis to
determine system moisture content and acid level.
IMPORTANT NOTE: Due to the hygroscopic properties
of the POE oil, all oil must be stored in metal containers.
The oil will absorb water if stored in a plastic container.
• Check the pressure drop across the oil filter. Refer to
“Maintenance Procedures “.
• Contact a qualified service organization to leak check
the chiller, to inspect safety controls, and inspect
electrical components for deficiencies.
• Inspect all piping components for leakage and/or
damage. Clean out any inline strainers.
• Clean and repaint any areas that show signs of
corrosion.
• Test vent piping of all relief valves for presence of
refrigerant to detect improperly sealed relief valves.
Replace any leaking relief valve.
• Inspect the condenser tubes for fouling; clean if
necessary. Refer to “Maintenance Procedures “.
• Check to make sure that the crank case heater is
working.
Scheduling Other Maintenance
Depending on chiller duty, contact a qualified service
organization to determine when to conduct a complete
examination of the unit to determine the condition of the
compressor and internal components.
Periodic Maintenance
Table 5 – Operating Conditions at Minimum Load R1234ze
Description Condition
Evaporator approach *< 4°C (non-glycol applications)
Condensing approach *< 4°C
Subcooling 1-2°C
EXV percent open 10-20% open
* 0.5°C for new unit.
