WSHP-SVX01Y-EN
109
Maintenance
WWAARRNNIINNGG
HHaazzaarrddoouuss SSeerrvviiccee PPrroocceedduurreess!!
FFaaiilluurree ttoo ffoollllooww aallll pprreeccaauuttiioonnss iinn tthhiiss mmaannuuaall aanndd
oonn tthhee ttaaggss,, ssttiicckkeerrss,, aanndd llaabbeellss ccoouulldd rreessuulltt iinn
ddeeaatthh oorr sseerriioouuss iinnjjuurryy..
TTeecchhnniicciiaannss,, iinn oorrddeerr ttoo pprrootteecctt tthheemmsseellvveess ffrroomm
ppootteennttiiaall eelleeccttrriiccaall,, mmeecchhaanniiccaall,, aanndd cchheemmiiccaall
hhaazzaarrddss,, MMUUSSTT ffoollllooww pprreeccaauuttiioonnss iinn tthhiiss mmaannuuaall
aanndd oonn tthhee ttaaggss,, ssttiicckkeerrss,, aanndd llaabbeellss,, aass wweellll aass tthhee
ffoolllloowwiinngg iinnssttrruuccttiioonnss:: UUnnlleessss ssppeecciiffiieedd ootthheerrwwiissee,,
ddiissccoonnnneecctt aallll eelleeccttrriiccaall ppoowweerr iinncclluuddiinngg rreemmoottee
ddiissccoonnnneecctt aanndd ddiisscchhaarrggee aallll eenneerrggyy ssttoorriinngg
ddeevviicceess ssuucchh aass ccaappaacciittoorrss bbeeffoorree sseerrvviicciinngg..
FFoollllooww pprrooppeerr lloocckkoouutt//ttaaggoouutt pprroocceedduurreess ttoo
eennssuurree tthhee ppoowweerr ccaann nnoott bbee iinnaaddvveerrtteennttllyy
eenneerrggiizzeedd.. WWhheenn nneecceessssaarryy ttoo wwoorrkk wwiitthh lliivvee
eelleeccttrriiccaall ccoommppoonneennttss,, hhaavvee aa qquuaalliiffiieedd lliicceennsseedd
eelleeccttrriicciiaann oorr ootthheerr iinnddiivviidduuaall wwhhoo hhaass bbeeeenn
ttrraaiinneedd iinn hhaannddlliinngg lliivvee eelleeccttrriiccaall ccoommppoonneennttss
ppeerrffoorrmm tthheessee ttaasskkss..
Preventative Maintenance
Maintenance on the unit is simplified with the
following preventive suggestions:
Filter maintenance must be performed to assure proper
operation of the equipment. Filters should be inspected
at least every three months, and replaced when it is
evident they are dirty. Filter sizing is shown below.
Table 58. Filter sizing GE* models
Size (60 Hz)
Size (50
Hz)
Filter Size (Nominal)
inches
GEH
006 — 15 x 20
009 006 15 x 20
012 009 15 x 20
015 012 15 x 20
018 015 18x24
024 018 18x24
030 024 18x24
035 030 19 x 26
042 036 19 x 26
048 042 21 x 30
060 048-060 21 x 30
072 —
20 x 25 (3)
090 072
20 x 25 (3)
120 090
20 x 25 (3)
Table 58. Filter sizing GE* models (continued)
Size (60 Hz)
Size (50
Hz)
Filter Size (Nominal)
inches
150 120
20 x 25 (3)
180 150
20 x 25 (3)
GEV
006 — 15x20
009 — 15x20
012 —
18x24
015 — 15x20
018 — 18x24
024 — 18x24
030 — 18x24
036 — 19x26
042 — 19x26
048 — 21x30
060 — 21x30
072 —
20 x 20 (4)
090 072
20 x 20 (4)
120 090
20 x 20 (4)
150 120
20 x 25 (6)
180 150
20 x 25 (6)
240 180
20 x 25 (6)
300 240
20 x 25 (6)
Check the contactors and relays within the control
panel at least once a year. It is good practice to check
the tightness of the various wiring connections within
the control panel.
A strainer (60 mesh or greater) must be used on an
open loop system to keep debris from entering the unit
heat exchanger and to ensure a clean system.
For units on well water, it is important to check the
cleanliness of the water-to-refrigerant heat exchanger.
Should it become contaminated with dirt and scaling
as a result of bad water, the heat exchanger will have to
be back flushed and cleaned with a chemical that will
remove the scale. This service should be performed by
an experienced service person.
