Installation
WWAARRNNIINNGG
PPrrooppeerr FFiieelldd WWiirriinngg aanndd GGrroouunnddiinngg
RReeqquuiirreedd!!
FFaaiilluurree ttoo ffoollllooww ccooddee ccoouulldd rreessuulltt iinn ddeeaatthh oorr
sseerriioouuss iinnjjuurryy..
AAllll ffiieelldd wwiirriinngg MMUUSSTT bbee ppeerrffoorrmmeedd bbyy qquuaalliiffiieedd
ppeerrssoonnnneell.. IImmpprrooppeerrllyy iinnssttaalllleedd aanndd ggrroouunnddeedd
ffiieelldd wwiirriinngg ppoosseess FFIIRREE aanndd EELLEECCTTRROOCCUUTTIIOONN
hhaazzaarrddss.. TToo aavvooiidd tthheessee hhaazzaarrddss,, yyoouu MMUUSSTT ffoollllooww
rreeqquuiirreemmeennttss ffoorr ffiieelldd wwiirriinngg iinnssttaallllaattiioonn aanndd
ggrroouunnddiinngg aass ddeessccrriibbeedd iinn NNEECC aanndd yyoouurr llooccaall//
ssttaattee//nnaattiioonnaall eelleeccttrriiccaall ccooddeess..
General Installation Checks
The checklist below is a summary of the steps required
to successfully install a commercial unit. This checklist
is intended to acquaint the installing personnel with
what is required in the installation process. It does not
replace the detailed instructions that are in the
applicable sections of this manual.
1. Remove packaging and inspect the unit. Check the
unit for shipping damage and material shortage; file
a freight claim and notify appropriate sales
representation.
The GEHE 0.5 to 5 ton units have been anchored to
the skid by (2) shipping bolts. The removal of these
bolts will require a 3/8 (9.7 mm) ratchet with a 0.5
(12.7 mm) socket.
The GEVG 0.5 to 5 ton and GEVE 6 to 25 ton units
have been anchored to the skid with (4) angle
brackets. Remove these brackets before lifting unit
into place.
The GEH 6 to 15 ton units are anchored to the cross
brace of the skid with (4) wood screws. Remove
these screws prior to lifting the unit into place.
2. Verify the correct model, options and voltage from
the unit nameplate.
3. Pull out all field attached parts (i.e. filter rack, duct
collar, filter and mounting screws) from the unit
packaging for field mounting.
4. Verify the installation location of the unit will
provide the required clearance for proper
operation.
5. Remove refrigeration access panel and inspect the
unit. Be certain the refrigerant tubing has clearance
from adjacent parts.
6. Fabricate and install duct work
7. Install and connect a condensate drain line and trap
to the drain connection.
Main Electrical
WWAARRNNIINNGG
HHaazzaarrddoouuss VVoollttaaggee!!
FFaaiilluurree ttoo ddiissccoonnnneecctt ppoowweerr bbeeffoorree sseerrvviicciinngg ccoouulldd
rreessuulltt iinn ddeeaatthh oorr sseerriioouuss iinnjjuurryy..
DDiissccoonnnneecctt aallll eelleeccttrriicc ppoowweerr,, iinncclluuddiinngg rreemmoottee
ddiissccoonnnneeccttss bbeeffoorree sseerrvviicciinngg.. FFoollllooww pprrooppeerr
lloocckkoouutt//ttaaggoouutt pprroocceedduurreess ttoo eennssuurree tthhee ppoowweerr
ccaann nnoott bbee iinnaaddvveerrtteennttllyy eenneerrggiizzeedd.. VVeerriiffyy tthhaatt nnoo
ppoowweerr iiss pprreesseenntt wwiitthh aa vvoollttmmeetteerr..
1. Verify the power supply complies with the unit
nameplate specifications.
2. Inspect all control panel components; tighten any
loose connections.
3. Connect properly sized and protected power supply
wiring to a field-supplied/installed disconnect
switch and to the main compressor contactor/
power block 1K1 (compressor contactor on the 0.5
to 5 ton) for GEH/V 0.5 to 5 tonor 1TB1 for GEH/V 6
to 25 ton equipment in the unit control panel .
4. Install proper grounding wires to an earth ground. .
NNoottee:: All field-installed wiring must comply with NEC
and applicable local codes.
Electric Heat Requirements
1. Verify that the power supply complies with the
electric heater specifications on the unit and heater
nameplate.
2. Inspect the heater junction box and control panel;
tighten any loose connections.
3. Check electric heat circuits for continuity.
Low Voltage Wiring (AC)
Requirements
1. Install the zone sensor or thermostat.
2. Connect properly sized control wiring to the proper
termination points between the zone thermostat or
sensor and the unit control panel.
Filter Installation
Each unit ships with 1 (25.4 mm) standard, 2 (50.8 mm)
standard, 2 in. MERV 8 or 2 in. MERV 13 filter. The
quantity of filters is determined by unit size. The GEH
0.5 to 5 ton units require field installation of the 1" or 2"
filters rack. All sheet metal bracket, filter and hardware
are in a box located on the side of the unit within the
unit packaging. All vertical and GEH 6 to 15 ton
horizontal units ship with the filter rack and filters
factory installed.
