Trane GEVE User Manual

46
WSHP-SVX01Y-EN
Figure 48. Return-air duct panel
Duct Panel
with 1 1/2"-Flange
A
Unit Side
Unit Side
Un
i
t
Top
B
1"
3 3/4"
Unit Top
Table 35. Opening size and part number GEH
Unit Size
(60 Hz)
Unit Size
(50 Hz)
A B
Duct
Collar
Part
Number
006-015 006-012 17.5 in. 13 in.
4474
1133
0100
018-030 015-024 20.5 in. 16 in.
4474
5628
0100
035-042 030-036 22.5 in. 17 in.
4474
1135
0100
048-060 042-060 26.5 in. 19 in.
4474
1136
0100
Table 36. Ducted panel — return air GEVG
Unit Size
(60 Hz)
A (in.) B (in.)
Duct Collar
Part
Number
GEVG006-
012
16.00 14.50
WSHPPN-
D00001
GEVG015-
018
18.50 16.50
WSHPPN-
D00002
GEVG024-
030
20.00 17.50
WSHPPN-
D00003
GEVG036-
042
23.00 18.50
WSHPPN-
D00004
GEVG048-
060
29.50 20.50
WSHPPN-
D00005
Ducted Filter Rack (GEH 0.5 to 5
tons only)
A
B
C
When it is necessary to have filter access at the unit in a
ducted return, a ducted filter rack is available. This
option allows access to the filter at the unit. Vertical
unit filter racks are available in right or left access
configurations. Horizontal units are available in top,
bottom or side access configurations.
Table 37. Ducted filter opening size GEH/V
Unit Size
A (in.) B (in.) C (in.)
GEH 006-015 21.1 15.40 5.4
GEH 018-030 24.5 18.40 5.6
GEH 035-042 26.4 19.40 5.5
GEH 048-060 30.7 21.40 5.5
