Trane RTAC 170 User Manual

RLC-SVX02G-E4
40
Wire Sizing
Table J-1 - Customer Wire Selection RTAC 120 - 200
Voltage
400/3/50
Standard
140 2x240 625 2x240
155 2x240 925 2x240
170 2x240 925 2x240
185 2x240 925 2x240
200 2x240 925 2x240
Standard Low Noise
140 2x240 625 2x240
155 2x240 925 2x240
170 2x240 925 2x240
185 2x240 925 2x240
200 2x240 925 2x240
High Efficiency
120 2x240 625 2x240
130 2x240 625 2x240
140 2x240 625 2x240
155 2x240 925 2x240
170 2x240 925 2x240
185 2x240 925 2x240
200 2x240 925 2x240
High Efficiency Low Noise
120 2x240 625 2x240
130 2x240 625 2x240
140 2x240 625 2x240
155 2x240 925 2x240
170 2x240 925 2x240
185 2x240 925 2x240
200 2x240 925 2x240
Extra Efficiency
120 2x240 mm² 6x250 + 3x125 2x240 mm²
130 2x240 mm² 6x250 + 3x125 2x240 mm²
140 2x240 mm² 6x250 + 3x125 2x240 mm²
155 2x240 mm² 6x400 + 3x125 2x240 mm²
175 2x240 mm² 6x400 + 3x125 2x240 mm²
185 2x240 mm² 6x400 + 3x125 2x240 mm²
200 2x240 mm² 6x400 + 3x125 2x240 mm²
Extra Efficiency Low Noise
120 2x240 mm² 6x250 + 3x125 2x240 mm²
130 2x240 mm² 6x250 + 3x125 2x240 mm²
140 2x240 mm² 6x250 + 3x125 2x240 mm²
155 2x240 mm² 6x400 + 3x125 2x240 mm²
175 2x240 mm² 6x400 + 3x125 2x240 mm²
185 2x240 mm² 6x400 + 3x125 2x240 mm²
200 2x240 mm² 6x400 + 3x125 2x240 mm²
Unit without
Disconnect Switch
Unit with
Disconnect Switch
Wire Selection Size to
Main Terminal Block Wire Selection Size to Disconnect Switch
Maximum cable
size mm²
Disconnect Switch
size (Amps)
Maximum cable
size mm
2
Unit
Size
Unit
Size
