RLC-SVX02G-E4
42
Electrical Data
Table E-1 - Electrical Data RTAC 120 - 200 ( 400/3/50)
Motor Data
Compressor (Each) Fans (Each) (6)
Unit Size Quantity cmpr 1 cmpr 2 cmpr 1 cmpr 2 Quantity kW FLA A kW
Standard
140 2 178 178 259 259 8 1.57 3.5 80 860 2.15 2.04
155 2 214 178 291 259 9 1.57 3.5 80 860 2.15 2.04
170 2 214 214 291 291 10 1.57 3.5 80 860 2.15 2.04
185 2 259 214 354 291 11 1.57 3.5 80 860 2.15 2.04
200 2 259 259 354 354 12 1.57 3.5 80 860 2.15 2.04
Standard Low Noise
140 2 178 178 259 259 8 1.57 2.0 80 860 2.15 2.04
155 2 214 178 291 259 9 1.57 2.0 80 860 2.15 2.04
170 2 214 214 291 291 10 1.57 2.0 80 860 2.15 2.04
185 2 259 214 354 291 11 1.57 2.0 80 860 2.15 2.04
200 2 259 259 354 354 12 1.57 2.0 80 860 2.15 2.04
High Efficiency
120 2 147 147 217 217 8 1.57 3.5 80 860 2.15 2.04
130 2 178 147 259 217 9 1.57 3.5 80 860 2.15 2.04
140 2 178 178 259 259 10 1.57 3.5 80 860 2.15 2.04
155 2 214 178 291 259 11 1.57 3.5 80 860 2.15 2.04
170 2 214 214 291 291 12 1.57 3.5 80 860 2.15 2.04
185 2 259 214 354 291 13 1.57 3.5 80 860 2.15 2.04
200 2 259 259 354 354 14 1.57 3.5 80 860 2.15 2.04
High Efficiency Low Noise
120 2 147 147 217 217 8 0.75 2.0 80 860 2.15 2.04
130 2 178 147 259 217 9 0.75 2.0 80 860 2.15 2.04
140 2 178 178 259 259 10 0.75 2.0 80 860 2.15 2.04
155 2 214 178 291 259 11 0.75 2.0 80 860 2.15 2.04
170 2 214 214 291 291 12 0.75 2.0 80 860 2.15 2.04
185 2 259 214 354 291 13 0.75 2.0 80 860 2.15 2.04
200 2 259 259 354 354 14 0.75 2.0 80 860 2.15 2.04
Extra Efficiency
120 2 147 147 217 217 8 1.57 3.5 80 860 2.15 2.04
130 2 178 147 259 217 10 1.57 3.5 80 860 2.15 2.04
140 2 178 178 259 259 10 1.57 3.5 80 860 2.15 2.04
155 2 214 178 291 259 12 1.57 3.5 80 860 2.15 2.04
175 2 259 178 354 259 13 1.57 3.5 80 860 2.15 2.04
185 2 259 214 354 291 14 1.57 3.5 80 860 2.15 2.04
200 2 259 259 354 354 14 1.57 3.5 80 860 2.15 2.04
Extra Efficiency Low Noise
120 2 147 147 217 217 8 0.75 2.0 80 860 2.15 2.04
130 2 178 147 259 217 10 0.75 2.0 80 860 2.15 2.04
140 2 178 178 259 259 10 0.75 2.0 80 860 2.15 2.04
155 2 214 178 291 259 12 0.75 2.0 80 860 2.15 2.04
175 2 259 178 354 259 13 0.75 2.0 80 860 2.15 2.04
185 2 259 214 354 291 14 0.75 2.0 80 860 2.15 2.04
200 2 259 259 354 354 14 0.75 2.0 80 860 2.15 2.04
Notes:
1. Maximum Compressors FLA + all fans FLA + control Amps
2. Starting Amps of the circuit with the largest compressor circuit including fans plus RLA of the second circuit including fans and control amps
3. Maximum FLA per compressor
4. Compressors starting amps, Star delta start
5. Compressor Power Factor
6. High static fans data - 100Pa ESP - Quantity same as standard fans, power input = 2.21kW each, FLA = 3.9 each
Maximum
Amps (3)
Starting
Amps (4)
Fan fuse
size (A)
Control
(VA)
Evaporator
heater
