RLC-SVX02G-E4
General Data
SI Units
Table G-1 - General Data RTAC 140-200 Standard
Size 140 155 170 185 200
Cooling capacity (5) (6) kW 491.9 537.3 585.4 648.0 714.5
Power input (7) kW 170.1 187.8 206 224.7 244.2
Energy Efficiency Ratio (5) (6) (as Eurovent) kW/kW 2.89 2.86 2.84 2.89 2.93
ESEER (as Eurovent) kW/kW 3.68 3.68 3.61 3.43 3.67
IPLV (According to ARI conditions 44°F leaving
water temperature, 95°F entering air temperature) kW/kW 4.20 4.16 4.10 4.09 4.19
Compressor
Quantity 2 2 2 2 2
Nominal Size (1) tons 70/70 85/70 85/85 100/85 100/100
Evaporator
Evaporator Model EH140 EH155 EH170 EH185 EH200
Water Storage l 112 122 127 135 147
Minimum Flow l/s 13 14 13 14 16
Maximum Flow l/s 44 49 46 49 55
Number of water passes 2 2 2 2 2
Condenser
Quantity of Coils 4 4 4 4 4
Coil Length mm 3962/3962 4572/3962 4572/4572 5486/4572 5486/5486
Coil Height mm 1067 1067 1067 1067 1067
Fin series fins/ft 192 192 192 192 192
Number of Rows 3 3 3 3 3
Condenser Fans
Quantity (1) 4/4 5/4 5/5 6/5 6/6
Diameter mm 762 762 762 762 762
Total Air Flow m
3
/s 35.45 39.19 42.94 47.23 51.53
Nominal RPM 915 915 915 915 915
Tip Speed m/s 36.48 36.48 36.48 36.48 36.48
Motor kW kW 1.57 1.57 1.57 1.57 1.57
Minimum Starting/Operating Ambient (2)
Standard Unit °C 0 0 0 0 0
Low-Ambient Unit °C -18 -18 -18 -18 -18
General Unit
Refrigerant HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a
Number of Independent
Refrigerant Circuits 2 2 2 2 2
% Minimum Load (3) 17 17 17 17 17
Operating Weight (4) kg 4481 4659 4794 5366 5488
Shipping Weight (4) kg 4363 4411 4692 5257 5367
Notes:
1. Data containing information on two circuits shown as follows: ckt1/ckt2
2. Minimum start-up/operation ambient based on a 2.22 m/s (5mph) wind across the condenser.
3. Percent minimum load is for total machine at 10°C (50°F) ambient and 7°C (44°F) leaving chilled water temperature, not each individual circuit.
4. With aluminium fins.
5. At Eurovent conditions, 7°C leaving water temperature and 35°C entering condenser air temperature.
6. Ratings based on sea level altitude and evaporator fouling factor of 0.017615 m²K/kW
7. Unit kW input, including fans
