Trane Tracer MP501 User Manual

24 CNT-SVX08F-EN
ZN: Zone Temperature
This input is not used if the controller is operating in generic mode. Neither the MP501 nor a BAS
system can use this input if the MP501 is configured as generic.
Outputs for Generic Applications
The MP501 includes four (4) outputs. Table 5 lists the outputs and their functions in generic mode.
Table 5. Outputs (generic mode)
Output Function
Binary output 1 Drive open or stage 1 (TRIAC)
Binary output 2 Drive close or stage 2 (TRIAC)
Binary output 3 Interlock device (relay)
Analog output (AO) Controlled actuator (0–10 Vdc)
Binary Output 1/Binary Output 2
Binary outputs 1 and 2 are 24 Vac TRIAC outputs that switch ac common. They can function in two
different ways:
• They can drive a tri-state modulating actuator. For some applications it may be more cost
effective to
use this type of actuator rather than a 0–10 Vdc actuator. Figure 9, p. 25 shows a
wiring diagram with the MP501 being used to control this type of actuator.
• Alternatively, binary outputs 1 and 2 can be used to control the two separate binary outputs in
stag
es. The MP
501 will first turn on stage 1 (binary output 1). Then, as the control loop senses
a larger demand, stage 2 (binary output 2) will be controlled on. Figure 10, p. 26 shows a wiring
diagram with the MP501 controlling staged outputs.
Note: Th
e MP501 controls
only one actuator. You cannot have both a 0–10 Vdc actuator and a tri-
state modulating actuator connected to the controller at the same time.
Binary Output 3
This binary output is a relay with a maximum current draw of 1 A. This relay energizes whenever
the control loop in the MP501 is enabled and de-energized when the control loop is disabled (refer
to the section, “Loop Enable/Disable,” p. 28). Typically, this relay controls a fan or pump. If the
control loop is disabled, the interlock relay is de-energized.
AO: Analog Output
The analog output on the MP501 is a 0–10 Vdc output with a maximum current draw of 10 mA from
the connected device. Figure 11, p. 27 shows a wiring diagram with the MP501 controllin
g this type
of actuator.
Note: The MP501 controls
only one actuator. You cannot have both a 0–10 Vdc actuator and a tri-
state modulating actuator connected to the controller at the same time.
Overriding Outputs
The MP501 includes a manual output test. Use this feature to manually control the outputs in a
defined sequence (refer to the section, “Manual Output Test,” p. 43).
Wiring Diagrams
Figure 9, p. 25 through Figure 11, p. 27 show three ways to wire the output on the MP501.
