Triumph BONNEVILLE SE User Manual

26
General Information
Speedometer
The speedometer indicates the road speed of
the motorcycle.
Odometer/Trip Meter
1. Odometer/trip meter/clock display
2. Reset button
The odometer shows the total distance that
the motorcycle has travelled.
There are two trip meters. Either trip meter
shows the distance that the motorcycle has
travelled since the meter on display was last
reset to zero.
To switch between the odometer and trip
meter display modes, press and release the
reset button until the desired display is visible.
The display will scroll through in the order:
•Odometer
• Trip meter 1
• Trip meter 2
•Clock
Trip Meter Reset
To reset either of the trip meters, select and
display the trip meter to be zeroed then press
the reset button for 2 seconds. After
2 seconds, the trip meter on display will reset
to zero.
1
2
Warning
Do not attempt to switch between
odometer and trip meter display modes or
reset the trip meter with the motorcycle in
motion as this may lead to loss of
motorcycle control and an accident.

Triumph BONNEVILLE SE Specifications

General

Displacement	865cc
Bore x Stroke	90 x 68 mm
Compression Ratio	9.2:1
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	5-speed
Frame	Tubular steel cradle
Engine Type	Air-cooled, DOHC, parallel-twin
Max Torque	68 Nm @ 5800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Exhaust	2-into-2 exhaust system
Front Suspension	41mm forks
Rear Suspension	Twin shocks
Front Brakes	Single 310 mm disc, 2-piston caliper
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.0in
Rear Wheel	17-inch
Rear Tire	130/80 R17
Wheelbase	1490 mm
Fuel Tank Capacity	16 liters
