Triumph BONNEVILLE SE User Manual

74
Maintenance and Adjustment
• Turn the outer cable adjuster to give
0.08 - 0.12 in (2 - 3 mm) of free play
at the clutch lever.
• Tighten the locknut.
• Use the lever adjuster to make
minor adjustments as necessary.
• Ensure all locknuts are secured at
both ends of the cable.
Drive Chain
For safety and to prevent excessive wear, the
drive chain must be checked, adjusted, and
lubricated in accordance with scheduled
maintenance requirements. Checking,
adjustment and lubrication must be carried
out more frequently for extreme conditions
such as dusty, wet, salty or heavily gritted
roads.
If the chain is badly worn or incorrectly
adjusted (either too loose or too tight) the
chain could jump off the sprockets or break.
Warning
A loose or worn chain, or a chain that
breaks or jumps off the sprockets could
catch on the engine sprocket or lock the
rear wheel.
A chain that catches on the engine
sprocket will injure the rider and lead to
loss of motorcycle control and an accident.
Similarly, locking the rear wheel will lead to
loss of motorcycle control and an accident.

Triumph BONNEVILLE SE Specifications

General

Displacement	865cc
Bore x Stroke	90 x 68 mm
Compression Ratio	9.2:1
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	5-speed
Frame	Tubular steel cradle
Engine Type	Air-cooled, DOHC, parallel-twin
Max Torque	68 Nm @ 5800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Exhaust	2-into-2 exhaust system
Front Suspension	41mm forks
Rear Suspension	Twin shocks
Front Brakes	Single 310 mm disc, 2-piston caliper
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.0in
Rear Wheel	17-inch
Rear Tire	130/80 R17
Wheelbase	1490 mm
Fuel Tank Capacity	16 liters
