27
General Information
Clock Adjustment
To set the clock, turn the ignition to the ON
position. Press and release the reset button
until the clock is visible in the display screen.
Press and hold the reset button for
4 seconds. After 4 seconds either 24 Hr or
12 Hr will be shown flashing. Press and
release the reset button to select the desired
clock display. When the correct display is
shown, do not touch the reset button until
the clock is shown with the hour display
flashing.
To reset the hour display, ensure that the
hour display is still flashing. Press the reset
button to change the setting. Each individual
button press will change the setting by one
digit. If the button is held, the display will
continuously scroll through in single digit
increments.
When the correct hour display is shown, do
not touch the reset button for 6 seconds. The
minutes display will begin to flash
automatically. The minutes display is adjusted
in the same way as for the hours.
Once both hours and minutes are correctly
set, do not touch the reset button for
6 seconds and the display will cease to flash
automatically.
1. C l o c k d i s p l a y
2. Hours read-out
3. Minutes read-out
Tachometer (where fitted)
The tachometer shows the engine speed in
revolutions per minute - rpm (r/min). On the
right side of the tachometer face is the 'red
zone'. Engine rpm (r/min) in the red zone is
above maximum recommended engine
speed and is also above the range for best
performance.
Do not attempt to adjust the clock with the
motorcycle in motion as this may lead to
loss of motorcycle control and an accident.
Never allow engine rpm to enter the 'red
zone' as severe engine damage may result.
