68
Maintenance and Adjustment
1. O i l f i l t e r
• Unscrew and remove the oil filter
using the Triumph service tool
T3880313.
• Discard the oil filter.
• Pre-fill the replacement oil filter with
new engine oil.
• Apply a smear of clean engine oil
to the sealing ring of the new oil
filter. Install the oil filter and tighten
to 7lbfft (10Nm).
• After the oil has completely drained
out, renew the sealing washer to the
drain plug. Install and tighten the
plug to 18 l b f f t ( 2 5 N m ) .
• Fit the skid pan and tighten the bolts
to 18 N m .
• Remove the oil filler plug.
• Fill the engine with oil (see page 69)
until it begins to show in the sight
glass.
• On Scrambler models, a suitable
funnel may be required to add oil to
the oil filler hole.
• Do not overfill or exceed the
capacities given in the Specification
section.
• Start the engine and allow it to idle
for a minimum of 30 seconds.
• Ensure that the oil pressure warning
light extinguishes shortly after
starting.
The oil may be hot to the touch. Avoid
contact with the hot oil by wearing suitable
protective clothing, gloves, eye protection
etc. Contact with hot oil may cause the skin
to be scalded or burned.
If the engine has recently been running,
the exhaust system will be hot. Before
working on or near the exhaust system,
allow sufficient time for the exhaust system
to cool as touching any part of a hot
exhaust system could cause burn injuries.
Raising the engine speed above idle,
before the oil reaches all parts of the
engine can cause engine damage or
seizure. Only raise engine speed after
running the engine for 30 seconds to allow
the oil to circulate fully.
