Truma AquaGo basic User Manual

40
APPENDIX D – Electrical Connection Diagram
-t°-t°
-t°
Flame Rectification Electrode - FRE Flame Ignition Electrode - FIE Water Flow Sensor - WFS
Power Switch
Internal Fuse
(10 A)
Power ON LED
Exhaust Pressure Switch - EPS
Water Over Temperature Switch - WOS
Exhaust Over Temp. Switch - EOS Burner Over Temp. Switch - BOS
Circulation Line Temperature Sensor - WCT *
12 VDC
* only AquaGo™ Comfort and AquaGo™ Comfort Plus
Safety Valve Modulator
Ground
Water Outlet Temperature Sensor - WOT Water Inlet Temperature Sensor - WIT
MOT
Flue Fan
If any of the original wire as supplied with the water heater must be replaced, it must be replaced with wire 18 AWG (** 16 AWG) - 105 °C - UL1015, or its equivalent
18 AWG or 1 mm2 MWG (** 16 AWG or 1.5 mm2 MWG)
(green)
(green)
(grey) (white)
( white) (grey) (blue) (red)
(red)
( red)
(blue)
( blue)
(red **)
Gas Valve
Circulation
Pump*
(orange)
(yellow)
(brown)
(black)
(black)
(black)
(black)
(black **)
(orange)
(orange)
(brown)
(yellow) (violet)
Error Code LED
Anti Freeze Element * (optional)
Control Panel * / Diagnosis
Fig. 35
