TSC TH240 Series User Manual

33
5 Operator Interface
Two operator interface options are available on the printers: LED User Interface and LCD User Interface. In addition to the two
physical user interfaces, you can also use Web User Interface to control and manage the printers.
5.1 LED User Interface
5.1.1 Control Panel
No.
Name
Description
1
Ribbon Out Indicator
Indicates the ribbon supply.
ON: The ribbon is used up.
Blinking: The ribbon roll is near the end.
2
Paper Out Indicator
Indicates the media supply.
ON: The media is used up.
Blinking: Paper is stuck in the printer.
3
Printhead Open Indicator
Indicates if the printhead is correctly closed.
ON: The printhead is open.
1
2
3
5
6
7
8
4
