TurboChef 2020 Service Manual

OVEN MODES
19
B
ottom Display Line
The bottom display line sho
ws enabled inputs
and outputs on the control board. The numbers
1-10 indicate the different bottom display line,
which are explained below.
NO
TE: A “-” or “_” display
ed on the bottom
display line denotes values that are in the off
mode or closed.
1
“R” r
epresents the real time clock pulse
used b
y the contr
ol board to time oven
functions. The “R” will blink once per
second.
2 The “1” shows that the rear belt’s conveyor
motor
’s Hall Effect Sensor (HES) is sending
a pulse to the contr
ol boar
d.
3
The “2” sho
ws that the fr
ont belt’s
conv
ey
or motor
’s HES is sending a pulse to
the contr
ol boar
d.
4
The “C” will only appear if the v
oltage is
below 220.
5 The “L” signifies that this is an electric
oven.
6 The “O” will only be missing during an F8:
High Limit Tripped fault.
7
The first “T” is displayed while the top air
BMSC reports an ok status to the control
boar
d.
8 The first “B” is displayed while the bottom
air BMSC reports an ok status to the
contr
ol board.
9 The second “T” is displayed while the top
air BMSC is enabled and r
eceiving a
command.
10
The second “B” is displayed while the
bottom air BMSC is enabled and r
eceiving
a command.
11 If the “F” is displayed, the belts are traveling
right to left. I
f the “F” is not display
ed, the
belts are traveling left to right.
Entering a New Serial Number
F
igure 27
1.
P
ress L1 (Figure 22, page 17) on screen 2 of
the TEST MODE to access the serial number
input screen.
2.
E
nter the new serial number.
-
The up key mo
ves up through the
-available characters. i.e. A,B,C…
-
The do
wn key moves down through the
-available characters i.e. A,+,-, ,9,8,…
- INS (L1) inserts a space.
- DEL (R1) deletes the selected character.
- ---> (R2) moves the cursor to the right.
- <--- (L2) moves the cursor to the left.
3.
P
r
ess R3 to save the changes or L3 to cancel.
