Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-4
(3) Connector lists
Connector Pin Signal I/O Voltage Description
YC2
1 EECLK I 0/3.3 V DC(pulse) Clock signal
Connected to
the connect-
left PWB
2 GND - - Ground
3 EESIO I/O 0/3.3 V DC Data signal
4 ERASER I 0/3.3 V DC CL control signal
5 +3.3V2_E2 I 3.3 V DC 3.3 V DC power input
6 TSENS O Analog TS output signal
7 SBMDIR I 0/5 V DC SBM: On/Off
8 WTSENS O Analog WTS output signal
9 SBMENBLN I 0/3.3 V DC SBM output control signal
10 WTLED I 0/3.3 V DC Waste toner LED control
11 SBMSTEP I 0/3.3 V DC SBM step signal
12 MPFSENS O 0/3.3 V DC MPS: On/Off
13 SBMMODE I 0/3.3 V DC SBM mode control signal
14 +3.3V1_E1 I 3.3 V DC 3.3 V DC power input
15 TMOT I 0/3.3 V DC TM: On/Off
16 LFANN I 0/24 V DC LFM: On/Off
17 *1 FUDR I 0/24 V DC FUSOL: On/Off
18 *1 ENVMOT I 0/5 V DC ENVM: On/Off
19 *1 FDDR I 0/24 V DC FUSOL: On/Off
20 *1 DUJAMSEN1
N
O 0/3.3 V DC DUS1: On/Off
21 *1 REGSEN2 O 0/3.3 V DC RS2: On/ Off
22 *1 REARSWN O 0/3.3 V DC RECSW: On/Off
YC3
1 +24V0_E3 I 24 V DC 24 V DC power input
Connected to
the connect-
left PWB
2 GND - - Ground
3 GND - - Ground
4 +24V2_E2 I 24 V DC 24 V DC power input
YC12
1 +3.3V2_E2 O 3.3 V DC 3.3 V DC power output
Connected to
the paper
feed sesor
2 GND - - Ground
3 PAPFULN I 0/3.3 V DC FS: On/Off
YC14 *1
1 +3.3V2_E2 O 3.3 V DC 3.3 V DC power output
Connected to
the lift sensor
2 GND - - Ground
3 LSENS I 0/3.3 V DC LS: On/Off

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
