Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-35
(3) Connector lists
Connector Pin Signal I/O Voltage Description
YC101
1 +24V2_E1 O 24 V DC 24 V DC power output
Connected to
the control
PWB
2 TCNT O Analog Transfer control
3 TRREM O 0/3.3 V DC Transfer remote signal
4 SCNT O Analog Separation control
5 +3.3V2_E2 O 3.3 V DC 3.3 V DC power output
6 DUJAMSEN2
N
I 0/3.3 V DC DUS2:On/Off
7 REGSENSN I 0/3.3 V DC RS:On/Off
8 PAPERSEN1
N
I 0/3.3 V DC PS1:On/Off
9 PAPERSEN2
N
I 0/3.3 V DC PS2:On/Off
10 BACNT I Analog Developer AC control
11 BDCNT I Analog Developer DC control
12 HVCLK O 0/3.3 V DC Developer clock signal
13 MDCCNT I Analog Charger DC control
14 MACCNT I Analog Charger AC control
15 MHVCLK O 0/3.3 V DC Charger clock signal
16 MISENS O Analog Charger current detection
17 GND - - Ground
18 ENVSENSN I 0/3.3 V DC ES:On/Off
YC102
1 +3.3V2_E2 O 3.3 V DC 3.3 V DC power output
Connected to
the envelope
sensor
2 GND - - Ground
3 ENVSENSN I 0/3.3 V DC FUPRS:On/Off

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
