Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-53
(3) Connector lists
Connector Pin Signal I/O Voltage Description
YC2
1 GND - - Ground
Connected to
the LCD
2 R0 O 0/3.3 V DC LCD Control signal
3 R1 O 0/3.3 V DC LCD Control signal
4 R2 O 0/3.3 V DC LCD Control signal
5 R3 O 0/3.3 V DC LCD Control signal
6 R4 O 0/3.3 V DC LCD Control signal
7 R5 O 0/3.3 V DC LCD Control signal
8 GND - - Ground
9 G0 O 0/3.3 V DC LCD Control signal
10 G1 O 0/3.3 V DC LCD Control signal
11 G2 O 0/3.3 V DC LCD Control signal
12 G3 O 0/3.3 V DC LCD Control signal
13 G4 O 0/3.3 V DC LCD Control signal
14 G5 O 0/3.3 V DC LCD Control signal
15 GND - - Ground
16 B0 O 0/3.3 V DC LCD Control signal
17 B1 O 0/3.3 V DC LCD Control signal
18 B2 O 0/3.3 V DC LCD Control signal
19 B3 O 0/3.3 V DC LCD Control signal
20 B4 O 0/3.3 V DC LCD Control signal
21 B5 O 0/3.3 V DC LCD Control signal
22 GND - - Ground
23 DCLK O 0/3.3 V DC LCD dot clock signal
24 3.3V O 3.3V DC 3.3 V DC power output
25 3.3V O 3.3V DC 3.3 V DC power output
26 3.3V O 3.3V DC 3.3 V DC power output
27 3.3V O 3.3V DC 3.3 V DC power output
28 DE O 0/3.3 V DC(pulse) LCD data enabling signal
29 HSYNC O 0/3.3 V DC(pulse) Horizontal synchronizing signal
30 VSYNC O 0/3.3 V DC(pulse) Vertical synchronizing signal
31 LED_EN O 0/3.3 V DC Backlight LED enabling signal
32 LED_PWM O 0/3.3 V DC Backlight LED control signal
33 TSC_INT - - Not used
34 I2C_SDA - - Not used
35 I2C_SCL - - Not used

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
