Vega ATEX User Manual

12
4 Mounting
VEGAMET 841 • 4 … 20 mA
58864-EN-200401
4 Mounting
4.1 General instructions
TheeldhousingoftheVEGAMET841isequallysuitableforoutdoor
or indoor installation due to its degree of protection IP66/IP67 and
Type 4X. The standard version is designed for wall mounting. A
mounting adapter for pipe mounting is available as an option.
The instrument is suitable for standard and extended ambient condi-
tions acc. to DIN/EN/IEC/ANSI/ISA/UL/CSA 61010-1. It can be used
indoors as well as outdoors.
Avoid direct sunlight or use the optionally available sun shade.
Makesurethattheenvironmentalandambientconditionsspeciedin
chapter "Technical data" are maintained.
Protect your instrument against moisture ingress through the following
measures:
•
Use the recommended connection cable (see chapter "Connect-
ing to power supply")
•
Tighten the cable gland
•
Mount the instrument in such a way that the cable glands point
downward
•
Loop the connection cable downward in front of the cable gland
This applies mainly to outdoor installations, in areas where high
humidity is expected (e.g. through cleaning processes) and on cooled
or heated vessels.
The visible area of the front panel must be protected from knocks,
otherwise water can penetrate through breaking of the front foil. In this
case, protection against accidental contact can no longer be ensured.
Caution:
Make sure that during installation or maintenance no moisture or dirt
can get inside the instrument.
To maintain the housing protection, make sure that the housing lid is
closed during operation and locked, if necessary.
The pressure compensation for the housing is realized via a breather
element.
Note:
Make sure that the pressure equalization element is always free of
buildup during operation. A high-pressure cleaner may not be used
for cleaning.
4.2 Mounting instructions
Fix the mounting plate to the wall using the screws and dowels sup-
pliedasshowninthegurebelow.Makesurethatthearrowsonthe
mounting plate point upwards.
Mounting options
Ambient conditions
Protection against mois-
ture
Pressure compensation
Wall mounting
